MODULE IV
Condensing boiler technology Page 54

Module IV ServitecStartPrevious pageNext pageEnd



Graphic: Experimental/test setup




English translation of technical terms and sentences of the diagram above:

Brennstoffgruppe = Fuel group
Gasgemisch = Gas mixture
Thermostat oder Einhandhebelmischer für eingangsseitige Temperaturwahl = Thermostat or lever mixer for the input temperature selection
Warmwasser = Hot water
Kaltwasser = Cold water
Temperatur-Messstellen = Temperature measuring points
Durchflussmengenmesser = Flow meter
Druckminderer = Pressure reducer
Kugelventil = Ball valve
Abfluss = Drainage
Kondensatablauf = Condensate drain
Abgasaustritt = Exhaust gas outlet
Verbrennungsluftbedarf = Combustion air requirement
Brennwert Ho = Calorific value Ho
Heizwert Hu = Heating value Hu
